electronIc IndIcAtors Ø.38"
New!
2700 Group 1 dIGItAl IndIcAtors .44" .58"
AGD GROUP 1
feAtures 3.07" .63" Ø.373" 3.36"
IndIca tors and GaGes • Two Available Displays - Single LCD Numeric IQ model (largest of .26" 1.16"
• 270 degree Rotating Bezel - Allows viewing at different attitudes
• Smaller Diameter - A dimensional match to AGD Group one
mechanical indicators (1.700"/43mm)

its class) with low battery warning and programmable ratios or
Numeric/Analog AD model showing its two displays simultaneously
• .400 travel
• Allows storage of 200 readings internally and viewed, stored
readings can be downloaded with included software and USB
style cable
• Easy wired communication with cables or using Starrett F2715AD
DataSure wireless (contact Starrett)
®
Ø1.54"
• Long battery life (with one CR232 cell) 3,000 hours under typical
use also can be powered by plugging into your computer

Inch/Metric - 8mm Stem - M2.5 x 0.45 Thread
Range Resolution Accuracy
Cat. No. EDP in mm in mm in mm
F2715IQ 72970 0.4 10 .001/.0005/.0001/.00005 0.02/0.01/0.002/0.001 ±.0001 ±0.002
F2715AD 72971 0.4 10 .001/.0005/.0001/.00005 0.02/0.01/0.002/0.001 ±.0001 ±0.002 Ø1.70" 1.54"
F2714IQ 73273 0.4 10 .001/.0005/.0001 0.02/0.01/0.002 ±.0001 ±0.002
F2714AD 73274 0.4 10 .001/.0005/.0001 0.02/0.01/0.002 ±.0001 ±0.002

3900 electronIc IndIcAtors
AGD GROUP 2
RANGES UP TO .500" AND 12.7MM
The 3900 Electronic Indicators have simple, powerful, easy-to-use functions, all at an attractive price.
Versions are available for inch/metric and metric only.
feAtures
• Large, easy-to-read LCD
• Power On/Off button
• Reverse travel (± control indicates direction)
• Zero setting at any position
• Long battery life
• 3/8" diameter stem for inch/mm model (8mm on metric-only model)
• 4-48 spindle thread on inch/mm model (M2.5 X .45 thread on metric-only model)
• Lug-on-center back with additional flat back
• Dust cap
• Plastic storage case with clear cover
3900-5
Range Resolution Accuracy
Cat. No. EDP in mm in mm in mm
3900-5 72538 .5 12.7 .0005 0.01 ±0.001 ±0.03
3900M-5 72537 12.7 0.01 ±0.03
Accessory
Cat. No. EDP Description
PT61918 67169 SR44 battery
