electronIc IndIcAtors
New!
2900 electronIc IndIcAtors
RANGES FROM .5" (12MM) TO 2" (50MM)
AGD GROUP 2
The 2900 Electronic Indicators are available in a choice of configurations to meet a range of requirements.
IndIca tors and GaGes IP67 protection and renowned Starrett quality, they maintain their reliability in hostile shop environments.
Innovative True Absolute Sensor Technology minimizes the chance of data loss for exceptional reliability. Built with

feAtures
• Intuitive design and layout – easy to learn and use
• Positive, tactile-feel button activation
• Long battery life
• CE compliant
• Data output to SPC on all models
• Choice of Basic, Standard and Advanced feature levels
• Fixed ratio measurement systems available
• Compatible with 25 Indicator backs 2900-1-2
• Origin set, zero set 2900-5-1
• All compatible with 2900 SCM, SCU and SCKB cables
• Counting direction switching (±) 2900-1

Inch/Metric -.375" Stem - #4-48 UNF Thread
Range Resolution Accuracy Additional Features
in/mm Limit Value Reading Selectable Ftr. Max/Min/Runout True Abs. Lug On CR2032

Cat. No. EDP in mm in mm in mm Cnv. Set Preset Hold Res. Lock Value Holding Sensor Tech. Ctr. Bck. Btry. (2)
2900-1 09980 .5 12 .00005 0.001 ±.00012 ±0.003 x x x x
2900-2 09981 .5 12 .0001 0.002 ±.00012 ±0.003 x x
2900-4 09983 .5 12 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x
2900-6 09985 .5 12 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x x
2900-1-1 09960 1 25 .00005 0.001 ±.00012 ±0.003 x x x x
2900-2-1 09962 1 25 .0001 0.01 ±.00012 ±0.003 x x
2900-3-1 09963 1 25 .0005 0.01 ±0.001 ±0.03 x x x
2900-4-1 09965 1 25 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x
2900-5-1 09967 1 25 .0005 0.01 ±0.001 ±0.03 x x x x x
2900-6-1 09969 1 25 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x x
2900-1-2 72676 2 50 .00005 0.001 ±.00012 ±0.003 x x x x
2900-4-2 72677 2 50 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x
2900-6-2 72678 2 50 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x x
Inch/Metric - 8mm Stem - M2.5 x 0.45 Thread
Range Resolution Accuracy Additional Features
in/mm Limit Value Reading Selectable Ftr. Max/Min/Runout True Abs. Lug On CR2032
Cat. No. EDP in mm in mm in mm Cnv. Set Preset Hold Res. Lock Value Holding Sensor Tech. Ctr. Bck. Btry. (2)

2900-1ME 09971 .5 12 .00005 0.001 ±.00012 ±0.003 x x x x
2900-4ME 09976 .5 12 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x
2900-6ME 09979 .5 12 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x x
2900-1ME-25 09972 1 25 .00005 0.001 ±.00012 ±0.003 x x x x
2900-3ME-25 09975 1 25 .0005 0.01 ±0.001 ±0.03 x x x
2900-4ME-25 09977 1 25 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x
2900-5ME-25 09978 1 25 .0005 0.01 ±0.001 ±0.03 x x x x x x x
2900-6ME-25 09991 1 25 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x x
2900-1ME-50 72679 2 50 .00005 0.001 ±.00012 ±0.003 x x x x
2900-4ME-50 72681 2 50 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x
2900-6ME-50 72683 2 50 .0005/.0001/.00005 0.01/0.001 ±.00012 ±0.003 x x x x x x x x x x
Metric Only - 8mm Stem - M2.5 x 0.45 Thread
Range Resolution Accuracy Additional Features
in/mm Limit Value Reading Selectable Ftr. Max/Min/Runout True Abs. Lug On CR2032
Cat. No. EDP in mm in mm in mm Cnv. Set Preset Hold Res. Lock Value Holding Sensor Tech. Ctr. Bck. Btry. (2)

2900-1M 09986 .5 12 0.001 ±0.003 x x x
2900-4M 09988 .5 12 0.01/0.001 ±0.003 x x x x x x x x
2900-6M 09990 .5 12 0.01/0.001 ±0.003 x x x x x x x x x
2900-1M-25 09961 1 25 0.001 ±0.003 x x x
2900-3M-25 09964 1 25 0.01 ±0.03 x x
2900-4M-25 09966 1 25 0.01/0.001 ±0.003 x x x x x x x x
2900-5M-25 09968 1 25 0.01 ±0.03 x x x x x x
2900-6M-25 09970 1 25 0.01/0.001 ±0.003 x x x x x x x x x
2900-1M-50 72680 2 50 0.001 ±0.003 x x x
2900-4M-50 72682 2 50 0.01/0.001 ±0.003 x x x x x x x x
2900-6M-50 72684 2 50 0.01/0.001 ±0.003 x x x x x x x x x
*Fixed ratios available with special order. (exception of 2900-5M-25)
