IndIcAtor AccessorIes

AGd IndIcAtor specIAl contAct poInts And AccessorIes

specIAl forM contAct poInts 3/8" (9.5) 3/8" (9.5) 1/8" (3) 3/32" (2.4) 1/2" (13)
Starrett Special Contact Points are furnished
IndIca tors and GaGes screw thread and can be used on any AGD 1/4" (6.3) 5/8" (16) 4 5/32" (4) 1/2" (13) 9/32" (7) 3/8" (9.5) 7/16" (11)
in fourteen shapes. Knurled diameter is
approximately 13/64" (5mm). All have #4-48
3/8" (9.5)
1/2" (13)
3
6
5
2
indicator. Other special shapes are available
on special order.
Carbide, sapphire, diamond or teflon-coated
contact points are also available by request.
25W roller contAct poInt
This contact has a small, hardened roller
3/8" (9.5mm) in diameter for continuous 7 1/16" (1.6) 8 1/32" (0.8) 9 10 11 1/16" (1.6)
gaging of moving material where the material
movement is at a slow speed. Contact has
#4-48 screw thread and substitutes for the 3/16" (4.7)
regular contact point provided on Starrett 1-7/16"
and other AGD indicators. Furnished with a 1" (25) (36.5) 2" (50) 9/16" (14)
knurled check nut for positioning the contact 3/8" (9.5)
on the indicator spindle. See drawing (right).
1/8" (3)
1/16" (1.6)
1/16" (1.6) 1/16" (1.6)
1/16" (1.6)
12 13 14 15 25W

AGd contAct AdApters 25r contAct poInt set
M 2.5 x .45 Thread 14 points with #4-48 screw thread to fit AGD indicators: a regular 1/4"
#4-48 Thread .195-.198" dia. #4-48 Thread
(6.3mm) long point; 9 special form points; a 28 Shock Absorbing Anvil; and
3 extra long points 1/2", 3/4" and 1" (13, 19, 25mm) long. High grade steel,
hardened and ground. All points are mounted on a convenient aluminum ring
for safe keeping and easy selection.
3/8" 9.5 mm
From Metric Racks to Inch Contacts From Inch Racks to Metric Contacts
PT24728 PT24729 PT06677-B PT06677-A
Contact Points PT06677
AGd contAct poInt extensIons Style No. Part No. EDP
2 PT06632-2 70790
3 PT06632-3 70791 8 PT01761
LENGTH 4 PT06632-4 70792
5 PT06632-5 70793
#4-48 6 PT06632-6 70794 6 9
#4-48 Thread Thread 7 PT06632-7 70795
8 PT06632-8 70796 28
9 PT06632-9 70797 10
10 PT06632-10 70798
11 PT06632-11 70799
12 PT06632-12 70800 5 2 25R
AGD Contact Point Extensions 13 PT06632-13 70801
Part No. EDP Length 14 PT06632-14 70802 7 4 3
PT21697-1/2 64632 1/2" 15 PT06632-15 70803
PT21697-1 64633 1" 25W 53916
PT21697-2 64634 2" 25R 50153
PT21697-3 64635 3" PT24728 64963
PT21697-4 64636 4" PT24729 64964

166
