IndIcAtor AccessorIes

AGd IndIcAtor contAct poInts And AccessorIes 28 sHocK AbsorbInG AnvIl
Any of the contact points listed here can also be used with the 650 and 651 Indicators Anvil replaces the regular contact point on any AGD
and with the 196 Indicators by using the 196R Adapter. indicator, protecting its movement against mechanical
shock. Any sudden impact telescopes the anvil into the
extrA-lenGtH reGulAr-style contAct poInts WItH round or flAt ends
body of the unit against an internal spring. Acts as a
1/4-4"/6-100MM solid contact point when the indicator is used normally.
All Starrett AGD indicators are regularly furnished with 1/4" (6.4mm) length Furnished with #4-48 AGD standard screw thread.
interchangeable contact points. Available in standard lengths to 4" (100mm).
Diameter is 13/64" (5mm), with a #4-48 screw thread. Made from high grade steel, Shock Absorbing Anvil IndIca tors and GaGes
hardened and ground. Other lengths are also available priced on application. Available Cat. No. EDP
with round or flat ends as listed. 28 50199

reGulAr-style cArbIde contAct poInts WItH round or flAt end
Two round points are available in standard lengths. 1/4" (6.3mm), PT08399-X (EDP
66053) – or – 1/2" (13mm), PT06677-X (EDP 66054). One flat point is available in flAt-end steel poInts
standard length; 1/4" (6.3mm), PT10453-X (EDP 66068). Interchangeable points
have a #4-48 screw thread. Longer lengths can be easily obtained by adding contact The flat-end contact points have hardened steel contact
point extensions (see next page). Other sizes also available by request. surfaces, ground flat and lapped. They are furnished with
a #4-48 screw thread for use on any AGD Indicator.

Extra-Length Contact Points, Regular Style Flat-End Steel Points
Rounded End Flat End Length Diameter
Part No. EDP Part No. EDP in mm Part No. EDP in mm Style No.
PT07215 70965 PT10453 72048 1/4 6.4 PT06632-17 70804 1/4 6.4 17
PT01761 75263 PT06632-18 70805 3/8 9.5 18
PT06677 70823 PT09560 71260 1/2 13 PT06632-19 70806 1/2 12.7 19
PT06677A 70824 PT09560A 71261 3/4 19 PT06632-20 70808 3/4 19 20
PT06677B 70825 PT09560B 71262 1 25 PT06632-21 70807 1 25 21
PT06677C 70826 PT09560C 71263 1-1/4 32
PT06677D 70827 PT09560D 71264 1-1/2 38
PT06677E 70828 PT09560E 71265 1-3/4 44
PT06677F 70829 PT09560F 71266 2 50
PT06677G 70830 PT09560G 71267 2-1/4 57 17 18 19
PT06677H 70831 PT09560H 71268 2-1/2 63
PT06677J 70832 PT09560J 71269 2-3/4 70
PT06677K 70833 PT09560K 71270 3 75 1/4" 3/8" 1/2"
PT10459 71327 4 100
20 21

3/4" 1"
