IndIcAtor Holders

661 MInI MAGnetIc 659 HeAvy-duty MAGnetIc bAse IndIcAtor Holder
IndIcAtor Holder
WITH ROTARY ON/OFF SWITCH. FURNISHED WITH OR WITHOUT STARRETT AGD
The Mini Magnetic Tool Holder is a simple, versatile, DIAL INDICATORS
effective and economical tool for a variety of indicator
holding tasks. It has no levers or switches – simply This holder has a powerful magnetic base that attaches to flat surfaces or on round work up to
place the holder on the measuring surface, attach 5" (125mm) in diameter by a form-ground involute vee for accurate seating. It has approximately
the indicator and position as required. twice the holding power of our 657 Magnetic Base and has a rotary on/off switch.
A post snug with two 3/4" (19mm) gripping holes positions the dial indicator at any
feAtures And specIfIcAtIons
height and at any vertical angle and allows for 360º rotation of the gage rod. After locking
• 30 lb (133 N) of holding force the gage in place, the final indicator setting is made by an independent fine adjustment IndIca tors and GaGes
• Base Diameter: 1.180" (30mm) at the back end of the gage rod.
• Base Height: 1" (25.4mm) A second tapped hole (3/8"-24) in one side of the base is for mounting the post horizontally
• Overall Height 4.173" (106mm) or adding another post for multiple inspection work. The base is furnished with a threaded
• Holds indicators with 3/8" stems or standard adapter, making it possible to use the 657 Magnetic Base post and attachments. Base
dovetail mounts and snug have a black wrinkle finish with precision ground contact surfaces.
• Fits over spindles and posts with diameter of Available with or without Starrett AGD Dial Indicators: inch reading 25-131J (.0005"
1/4" (6.3mm), such as the 196 Dial Indicator graduation) or millimeter reading 25-181J (0.01mm graduation). Other mechanical
• Includes an 8mm adapter for indicators with AGD indicators are available on request. Electronic indicators, 2600 and 2700, are also
metric (8mm) stems available on request.
Both the upright post and the gage rod are approximately 9 3/8" (238mm) long and 3/4"
(19mm) in diameter.

661 Mini Magnetic Indicator Holder Base Holder Assembly and Individual Components
Cat. No. EDP Description Photo Key Cat. No. EDP Description
661 68620 Indicator Holder Magnetic Base, Upright Post Assembly Including Post, Snug, Gage Rod with
659A 56687
Clamp and Fine Adjust, and Thread Adapter, without Case
659AZ 55947 Complete Assembly (Above) in Case
P 659P 55949 Magnetic Base, Including Thread Adapter
G 659G 56688 Upright Base Post Only
H PT16846 71597 Swivel Post Snug Only with Two 3/4" (19mm) Gripping Holes
J PT08903 72032 Gage Holding Rod Only, Including Clamp Mechanism and Fine-Adjustment
PT18318 72040 Thread Adapter Only
Sets, Including Magnetic Base, Upright Post Assembly and AGD Dial Indicators
661with 196 Indicator Cat. No. EDP Description
659BZ 55948 Base and Upright Post Assembly with Inch Reading Indicator 25-131J in Case
661 659MBZ 64892 Base and Upright Post Assembly with Millimeter Reading Indicator 25-181J in Case

G

661with 709 Indicator
H

661with 81 Indicator
659BZ
J

P

659MBZ

starrett.com 181
