IndIcAtor Holders

665 InspectIon Holder And dIAl IndIcAtors Three very useful inspection combinations can be made by
This is the most versatile dial indicator holder with an extremely stable base removing the complete swivel post snug and gage holding
(A) that is 8-1/2" (215mm) long x 2-1/4" (57mm) wide at the bottom. It can rod as follows:
inspect workpieces on the top surface of the ground base or within a working G. Clamp 665G
area defined by the 8" (200mm) upright base post (B) and the 9-1/2" (238mm) Take the clamp and put the clamp post into the snug and
long gage-holding rod (C). The base post can be conveniently located anywhere lock it. Now this combination can be used to clamp the gage
along the 8-1/2" (215mm) T-slot in the base. holding rod and the indicator into hard-to-reach places for
This tool can be held in a vise or by a bolt in a machine T-slot coming up through one inspecting jigs, fixtures, lining up work on centers and
of the two 3/8" (9.5mm) holes in the base and fastening down on the top surface. machine tables. IndIca tors and GaGes
D. Swivel Post Snug 665D The clamp has a 3" (75mm) capacity and a post with an
approximately 5-3/4" (145mm) length. The clamp post is
Snug has a .375" (9.5mm) hole for the gage holding rod and a .465" (11.8mm)
hole for the upright post. Also comes with the 665L Reducing Bushing (J) that .464" (11.8mm) diameter that fits into the regular swivel
can reduce the .465" (11.8mm) hole to 3/8" (9.5mm). post snug 665D.
Three other clamp post diameter options available – 665G-
3/8 is a 3/8" (9.5mm) diameter clamp post that can be
Individual Components
Key Cat. No. EDP Description used in the regular swivel post snug 665D with the addition
A 665A 52783 Base Only of the 665L reducing bushing. The 665G-5/16 (7.9mm)
B 665B 52784 Upright Base Post .464" x 8" (11.8 x 200mm) with Clamp Mechanism and 665G-1/4 (6.3mm) can be used with other snugs to
Gage Holding Rod 3/8" x 9-1/2" (9.5 x 240mm) with hold an indicator.
C PT06784-A 52755
Clamp Mechanism
Swivel Post Snug with .465" and 3/8" (11.8 and 9.5mm) holes H. Tool Post Holder 665H
D 665D 52754
with 665L Reducing Bushing
G 665G 52792 Clamp with .464" x 5-3/4" (11.8 x 146mm) Post Put one end of the offset arm into the swivel post snug
665G-1/4 52793 Clamp with 1/4" (6.3mm) Diameter Post 665D (with the 665L reducing bushing in it). Then put this
665G-5/16 52794 Clamp with 5/16" (7.9mm) Diameter Post rectangular tool post holder 665H onto the other arm. This
665G-3/8 52795 Clamp with 3/8" (9.5mm) Diameter Post combination now allows for a good, tight setup in lathe tool
H 665H 52790 Tool Post Holder Approximately 1" x 7/16" (25 x 11mm) posts and other machine setups.
I 665G-1 52789 Offset Arm 3/8" (9.5mm) Diameter 3" and 5 1/2" (75 and 140mm) Arms
Reducing Bushing Only (for Swivel Post Snug) .465" (11.8mm) O.D. I. Offset Arm 665G-1
J 665L 52756
.375" (9.5mm) I.D.
Inspection Sets with AGD Dial Indicators Another very popular measuring combination is to put the
Cat. No. EDP Description reducing bushing (which is furnished) into the snug and then
665JZ 56275 Complete with Components and 25-131J Inch Reading Indicator in Case put one leg of the offset arm into it. Now the tool can be used
665MJZ 56276 Complete with Components and 25-181J Millimeter Reading Indicator in Case in a 3/8" (9.5mm) chuck or collet to sweep a large area.

C D

B

A

665JZ with 25-131J Indicator
