WIRELESS DATA COLLECTION A wide variety of End Nodes are available, allowing
DataSure to interface with electronic measuring
tools from virtually all major manufacturers
®
AddInG dAtAsure to your fAcIlIty
To add DataSure to your facility, simply contact us. We will work with you to
specify a system for your application.
We will add new End Nodes and Output Connectors to those listed below as
needed. Please call to discuss your requirements. Da t a ColleCtion SyStemS
Note that new End Nodes or Routers for a current system must be made to match the
Group Number of your existing components.
DataSure Gateway, Routers
Cat. No. EDP Description
1500-1-N 12051 Gateway, USB, 917MHz
1500-2-N 12059 Router, 916MHz, 120/240 VAC
PT62742 62024 Gateway or Router Mounting Bracket
DataSure End Nodes, Connectors and Accessories
Cat. No. EDP Tool Type Description
1500-3A-2N 12531 Micrometer End Node, Starrett 795 Series
1500-3A-3N 12532 Micrometer End Node, Starrett 3rd Gen., 733 Style Micrometer Head
1500-3A-9N 12538 Micrometer End Node, Mitutoyo 500-6XX, 500-7XX Series
1500-3A-10N 12539 Micrometer End Node, Mitutoyo 293-2XX, 293-3XX Series
1500-3A-24N 72536 Micrometer End Node, Starrett 795.1 Series
1500-3A-18N 12565 Micrometer/Slide Caliper End Node, Starrett Proximity 770B Micrometers, 798 Calipers, and 781 3-Button
1500-3A-1N 12530 Slide Caliper End Node, Starrett Opto, 797 Series, 781 2-Button
1500-3A-23N 72662 Slide Caliper End Node, Starrett EC799 Slide Caliper
1500-3A-7N 12536 Slide Caliper/Indicator End Node, Mitutoyo with and without Absolute Encoder
1500-3A-4N 12533 Indicator End Node, Starrett 2700 Series
1500-3A-21N 00046 Indicator End Node, Starrett 2900 Series
1500-3A-13N 12542 Indicator End Node, Mitutoyo 543-5XX Series
1500-3A-5N 12534 Other End Node, Starrett Cat. No. 2000 Series
1500-3A-15N 12544 Other End Node, Starrett 782, 781, 797 Series, TESA-CAL, TESA Intrimik
1500-3A-6N 12535 Other End Node, Mitutoyo 6-Pin Round
1500-3A-8N 12537 Other End Node, RS232, DB9 Tools with TX, RX, GND
1500-3A-11N 12540 Other End Node, Marposs E4N
1500-3A-12N 12541 Other End Node, Universal 10-pin connector
1500-3A-14N 12543 Other End Node, Mahr-Federal with µMaxum and XL
1500-3A-16N 12545 Other End Node, Mahr-Federal EX
1500-3A-20N 69854 Other End Node, TESA Microhite
PT62785-0 12188 Accessory Mushroom Head Fastener Kit to Attach End Nodes to Tool (Two pair included with each end node)
DataSure Replacement Output Connectors
Cat. No. EDP Tool Type Description
PT63298-2N 12547 Micrometer Replacement Output Connector, Starrett 795 Series
PT63706-22N 73325 Micrometer Replacement Output Connector, Starrett 780 Bore Gage
PT63473-24N 73327 Micrometer Replacement Output Connector, Starrett 795.1 Series
PT63305-9N 12554 Micrometer Replacement Output Connector, Mitutoyo 500-6XX, 500-7XX Series
PT63306-10N 12555 Micrometer Replacement Output Connector, Mitutoyo 293-2XX, 293-3XX Series
PT63300-4N 12549 Indicator Replacement Output Connector, Starrett 2700 Ind.
PT63536-21N 73324 Indicator Replacement Output Connector, Starrett 2900
PT63389-18N 12562 Slide Caliper Replacement Output Connector, Starrett 798 Calipers, Proximity 781 3-Button
PT63660-23N 12547 Slide Caliper Replacement Output Connector, Starrett EC799 Caliper
PT63297-1N 12546 Other Replacement Output Connector, Starrett Opto, 797 Series, 781 2-Button
PT63299-3N 12548 Other Replacement Output Connector, Starrett 3rd Gen., 733 Style Micrometer Head
PT63301-5N 12550 Other Replacement Output Connector, Starrett 2000/2001/3752 Series
PT63302-6N 12551 Other Replacement Output Connector, Mitutoyo 6-Pin Round
PT63303-7N 12552 Other Replacement Output Connector, Mitutoyo without Absolute and with Absolute
PT63310-14N 12559 Other Replacement Output Connector, Mahr Federal Umaxum Indicator
PT63312-16N 12561 Other Replacement Output Connector, Mahr Federal Ex
PT63304-8N 12553 Other Replacement Output Connector, RS232, DB9 Tools with TX, RX, GND
PT63307-11N 12556 Other Replacement Output Connector, Digimatic W/D-Sub 9 Pin
PT63308-12N 12557 Other Replacement Output Connector, Universal Mitutoyo 10 Pin
PT63309-13N 12558 Other Replacement Output Connector, Absolute Digimatic
PT63311-15N 12560 Other Replacement Output Connector, Opto/Duplex
PT63533-20N 73320 Other Replacement Output Connector, TESA Microhite
