GAGe AMplIfIers feAtures

GaGe amps, Hardness and surf ace TesTers in measurements. • Selectable inch or millimeter ranges
717 electronIc GAGe AMplIfIer
• Dual inputs for cumulative/differential measurements
Starrett has made electronic gaging easier with the 717 Electronic Gage
Amplifier. The large analog display is easy to read and shows real-time change
• Selectable digital or analog output
The 717 Gage Amplifier is flexible and has an accuracy within ±2% of full scale.
• Simple "push-button" calibration
Ranges vary from ±.010" to ±.0001" (±0.200mm to ±0.002mm), with gage
• Mirrored gage display for parallax-free readability
graduations from .0005" to .000005" (0.01mm to 0.0001 mm).
• Rugged metal case can be used anywhere in the shop
• Uses standard Starrett lever and cartridge-type probes
67001 Amplifier with Power Supply Charger
717
• Remote zero using PC
715-1Z
64479 Lever-Type Gaging Head Range ±.010" (0.25mm)
715-2Z
Cartridge-Type Gaging Head Pneumatic-Push, Length 2-3/4" (70mm) Range
715-6
64186
• Single and continuous data send modes
±.040" (0.100mm)
64187 Cartridge-Type Gaging Head Length 1-3/8" (35mm) Range ±.020" (0.50mm)
715-7
• Serial Data Output via front panel button, PC or
64188 Cartridge-Type Gaging Head Length 2-1/2" (64mm) Range ±.040" (0.100mm)
715-8 64480 Cartridge-Type Gaging Head Length 2-1/2" (64mm) Range ±.020" (0.50mm) • Front panel data send button
optional foot switch
715-9 64189 Cartridge-Type Gaging Head Length 3-5/8" (92mm) Range ±.080" (0.200mm)
Height Gage and Comparator Attachment 1/4 x 1/2" (6.3 x 13.5mm) (Adapts AccurAcy
PT99441 52991 Gaging Heads to Height Gages, Magnetic Base Indicator Holders, Dial • Within ±2% of full scale
Comparators and Test Indicator Stands.) .375" (9.5mm) Snug Hole
PT60636 63839 Power Supply Charger for USA and Canadian Configuration – 115/120 Volts/60 Cycle poWer requIreMents
PT99353 66456 Power Supply Charger for United Kingdom Configuration – 100-240 VAC, 47-63Hz • 110 volt VAC/60Hz (AC adapter furnished)
PT99340 66455 Power Supply Charger for European Configuration – 100-240 VAC, 47-63Hz dAtA output
PT60642 72499 Cable to Computer (9-Pin to 9-Pin)
728-3 66662 Shop Floor Pro Software • Digital: ASCII serial data
™
™
719 66490 Software Wedge Program for Interfacing to Spreadsheets • Analog: ±2.5 VDC/Full scale
sIZe
• Dimensions: 9-1/4" Height x 5-1/2" Width x 5-1/2"
Depth (235 x 140 x 140mm)
Ranges/Graduations
Range • Weight: 6 lb (2.7kg)
in Each Gage Graduation
±.010 .0005
±.002 .0001
±.001 .00005
±.0002 .00001
±.0001 .000005
mm
±0.200 0.01
±0.100 0.005
±0.020 0.001
±0.010 0.0005
±0.002 0.0001

717

717 Electronic Gage Amplifier with 252 Transfer
Gage and 715-1Z Gaging Head
