GAGe AMplIfIers
New!
rMs reMote dIsplAy feAtures
The Remote Display allows for the connection of up to four gages and displaying • 7" Android tablet with intuitive software application for
their current measurements into an Android application. In addition, the Remote easy process monitoring, setup, and data export
Display can connect to up to two external data consumers (desktop computer, • Flexible data requesting and logging (.CSV to Micro
laptop, PLC, or any generic serial device) over RS-232 and USB. SD Card, E-mail, PC transfer) with programmable auto
The Remote Display has been designed to work with nearly any gauge that logging and collection
outputs data in Digimatic format. This includes all 2700 Indicators. In addition, • Simultaneous connection of up to four devices GaGe amps, Hardness and surf ace TesTers
devices that output raw quadrature can be used as well. (Indicators, Calipers, Micrometers, Probes, etc.)
As a standalone measurement system, the Remote Display provides a very • Supports both Digimatic and Quadrature gaging systems
intuitive and user-friendly way to configure and monitor several gages at once. • "Send All" or "Request All" data to/from all gages
Connecting the Remote Display to a computer or other serial device makes data • TIR, Max., Min. and Freeze Hold, Travel Reverse
collection and statistical process control (SPC) simple and easy. • USB Type A and B, RS232 connection
• High quality, low profile enclosure
Electronic Measurement System
Cat No. EDP Description • Bright LED power indication
RMS2704 72954 RMS4 readout/data collection system with tablet, software MUX box • IN, MM and No Units setting
Probes • Programmable Ratios
Description/Range Resolution
Cat No. EDP in mm in mm AGD Size • Four channel view
P27300-1 72955 .060 1.5 .0001 .002 2
P27300-0 72956 .060 1.5 .00005 .001 2
P27400-1 72957 .150 3.8 .0001 .002 2
P27400-0 72958 .150 3.8 .00005 .001 2
P27500-1 72959 .250 6.35 .0001 .002 2
P27500-0 72960 .250 6.35 .00005 .001 2
P27600-1 72961 .600 15 .0001 .002 2
P27600-0 72962 .600 15 .00005 .001 2
P27211-1 72963 1.0 25.4 .0001 .002 3
P27211-0 72964 1.0 25.4 .00005 .001 3
P27720-1 72965 2.0 50 .0001 .002 RECT
P27820-1 72966 4.0 101.6 .0001 .002 RECT
Accessories
Part No. EDP Description
PT05937 72967 Push button remote global data send cable for MUX Box with 2.5mm plug
PT05679 68752 6' Extension Cable

Complementary Electronic Equipment
Cat No. EDP Description
EC799BSCM 46000 SmartCable Gage MUX - EC799B Slide Caliper
798SCM 69894 SmartCable Gage MUX - 798 Slide Caliper
795.1SCM 01124 SmartCable Gage MUX - 795.1 Micrometer
733SCM 69893 SmartCable Gage MUX - 733 Micrometer
2900SCM 68751 SmartCable Gage MUX - 2900 Indicator
2700SCM 69896 SmartCable Gage MUX - 2700 Indicator
2000SCM 69907 SmartCable Gage MUX - 2000-24 Height Gage

Backs/Lever*
Part No. EDP Description RMS2704
PT26406 65886 Flat Back
PT26407 65887 Offset Lug Back
PT26411 65891 Adjustable Lug Back
PT26408 65888 Adjustable Back
PT26409 65889 Post-Type Back
PT26410 65890 Screw Bracket Back
PT26848 66293 Adjustable Mounting Bracket Back
PT26405 65885 Lifting Lever
*Other backs, styles and accessories also available by request. To order contact points individually, see previous pages.
