GAGe AMplIfIers feAtures

™
GaGe amps, Hardness and surf ace TesTers defined formulas. GAGE-CHEK also reports dynamic Min/Max measurements, • Supports 1, 4 or 8 input channels. These can be
776 GAGe-cHeK MultI-AxIs MeAsured vAlue dIsplAy
• Large (6") color flat-panel LCD screen built into
The Gage-Chek 776 is a multi-axis measured value display that accepts up to
™
a compact ergonomically designed case with an
eight probe inputs. It features intuitive visual display, helpful audio cues and user-
adjustable tilt base allows comfortable positioning
for the operator
provides SPC analysis from an integrated database, and includes connectivity to
PCs and other Starrett tools.
mathematically combined to display dimensions such
as flatness, volume or runout.
Specifications 776 Gage-Chek Multi-Axis Measured Value Display
6" color
LCD
• Screens include individual readings with the capacity
.45"
Display Digit Size
to display four lines simultaneously (each line 9/16"
Resolution Down To
.000004"/.0001mm
high), bar and dial position style displays, graphs and
Operating Temperature 32º - 115 °F
histograms of measurement statistics, and tables of
Enclosure (W x H x D)
measurement and SPC data
Base Width (W x H x D) 10 x 2 x 7.5"
Enclosure Weight
3.5 lbs
Base Weight 11.5 x 7.5 x 2.75" • Supports Starrett 776 LVDT probes and Heidenhain
7 lbs
Input Voltage Range 85 VAC - 264 VAC Specto style 12mm and 30mm range digital probes
Input Frequency 43 Hz - 63 Hz • Measurements can be taken by the operator or in a
Inputs 1-, 4- and 8-axis input available semi-automated manner
External Connections Foot Switch, Remote Keypad, Touch Probe, RS232C Serial Port, Parallel Port
Outputs 2 Relay Outputs • Large comfortable buttons allow easy selection of
measurement functions, display screen changes, data
entry and zeroing the screen
• Speaker and external jack outputs can be adjusted to
compensate for noisy work environments. Earphones
can be plugged into speaker jack for silent operation.
• Two 3 x 1/2" keys placed over the screen can be
programmed as hot keys for frequently used functions
• Optional foot switch available

The 776 accepts multiple gage inputs simultaneously – invaluable for
applications such as this Starrett special gage fixture

776
