sMArtcAbles ™

sMArtcAbles feAtures And specIfIcAtIons
• Simple Set-up, your PC automatically installs USB driver
EASY TOOL-TO-PC CONNECTION AND DATA TRANSFER
Da t a ColleCtion SyStemS interface provides the ability to connect through USB and USB keyboard outputs. • Simple plug and play set up – doesn't require
when the SmartCable is plugged into PC's USB port
SmartCable makes it fast and easy to connect a measuring tool to a PC. The
• Supports USB 2.0, RS232 and Keyboard (optional) output
With the SmartCable keyboard output, no software wedge or other intermediary
software configuration
software is required. The PC "sees" the connection from the SmartCable as a
• Operating modes: Static (Normal) mode operation or
keyboard. Simply, open any document on your computer that accepts input,
Dynamic (MIN/MAX/TIR)
position your cursor, then send the data from the tool. That data will be input at
• LED status light
the cursor location.
With SmartCable USB output, requires 719 Software Wedge or a similar product
to input the data to the PC.
From manufacturing methods and materials to a built-in, power-saving mode,
the SmartCable was designed to be an environmentally friendly product.
Smart Cable Products
Cat. No. EDP Description 719 softWAre WedGe ™
733SCU 69898 SmartCable USB Ouput for 733 Micrometer and 2600 indicator type output
733SCKB 69888 USB cable to PC (In focused window) Data collection software for serial
795SCU 69897 SmartCable USB Ouput for 795 Micrometer devices. WinWedge captures data
795SCKB 69887 USB cable to PC (In focused window) directly to Excel, Access or any
795.1SCU 01126 SmartCable USB Output for 795.1 and 733.1 Micrometer Windows application or web page.
795.1SCKB 01125 USB cable to PC (In focused window) Send commands out a COM port so
797SCKB 69890 USB cable to PC (In focused window)
798SCKB 69889 USB cable to PC (In focused window) you can control your device through 719 Software Wedge
EC799BSCU 46002 SmartCable to USB hot keys, buttons, or DDE. Works with
EC799BSCKB 46001 USB cable to PC (In focused window) all cables and DataSure.
2000SCKB 69908 USB cable to PC (In focused window)
2700SCKB 69891 USB cable to PC (In focused window)
2900SCU 68712 SmartCable USB Output for 2900
2900SCKB 68839 USB cable to PC (In focused window)
719 66490 Software Wedge allows direct input to PC
PT26441 65893 2700 USB Connection

Direct RS232 9-Pin Connection Cables
Part No. EDP For Use with Starrett Tool Numbers
PT61963 66636 714, 760, 786, 733, 762, 788, 749, 764, 790, 751, 769, 2600-1, 753, 773, 2600-4, 756, 777, 2600-8, 3752
PT62425 67658 2000, 2001
PT62606 68822 797B, 5000, 5001, 5002, 5003, 5004, 5005, 5006, 781; Opto Connection
PT63329 12732 798, USB Connection, 770B, 781B; Proximity Connection

RS232 9-Pin Connection Cable

798SCKB
