electronIc MIcroMeters

3732 electronIc MIcroMeters feAtures And specIfIcAtIons
(WItHout output) • Automatic OFF after 30 minutes of nonuse

0-6"/0-150MM • .250" (6.35mm) spindle diameter
The 3732 Electronic Micrometer is a full-featured precision measuring tool built with • No-glare black wrinkle finish on frame
customary Starrett quality and workmanship. The 3732 includes a large, easy-to-read, • No-glare satin chrome finish on thimble and sleeve
high contrast LCD digital readout for clear readings. With its automatic OFF functionality, • Ring-type knurled lock nut for quick and
smooth friction thimble for uniform pressure, and balanced frame design, the 3732 sure locking
provides comfortable and accurate measuring. • English/Metric models feature inch graduations
on shell and thimble
3732 Inch/Metric Micrometers without Output
Range Resolution Accuracy • Metric/English (ME) models have mm
Cat. No. EDP MicroMeters
in Approx. mm in mm in mm graduations on shell and thimble
3732XFL-1 12268 0-1 0-25.4 0.0001 0.001 ± 0.0001 ± 0.002 • Instant inch/millimeter conversion
3732XFL-2 12269 1-2 25.4-50.8 0.0001 0.001 ± 0.0001 ± 0.003
3732XFL-3 12270 2-3 50.8-76.2 • Measurement HOLD button
3732XFL-4 12271 3-4 76.2-101.6 0.0001 0.001 ± 0.00015 ± 0.004 • Ability to zero tool at any position
3732XFL-5 12272 4-5 101.6-127 0.0001 0.001 ± 0.00015 ± 0.004
3732XFL-6 12273 5-6 127-152.4 • Ability to retain and return to the true zero
3732 Metric/Inch Micrometers without Output reading of the micrometer
Cat. No. EDP mm Approx. in mm in mm in • PRESET button to install any reading at any position
3732MEXFL-25 12274 0-25 0-.984 0.001 0.0001 ± 0.002 ± 0.0001
3732MEXFL-50 12275 25-50 .984-1.968 0.001 0.0001 ± 0.003 ± 0.0001 • Includes one 3-volt battery for over one year
3732MEXFL-75 12276 50-75 1.968-2.953 of normal usage
3732MEXFL-100 12277 75-100 2.953-3.937 0.001 0.0001 ± 0.004 ± 0.0001
3732MEXFL-125 12278 100-125 3.937-4.921 0.001 0.0001 ± 0.004 ± 0.0001
3732MEXFL-150 12279 125-150 4.921-5.905
3732 Inch/Metric Micrometer Sets without Output
Cat. No. EDP in mm Description
S3732BXFLZ 12726 0-1 to 3-4 0-25.4 to 76.2-101.6 0 to 4 inch set of four micrometers in metal case
S3732CXFLZ 12727 0-1 to 5-6 0-25.4 to 101.6-152.4 0 to 6 inch set of six micrometers in metal case
3732 Micrometer Accessories
Part No. EDP Description
PT99492 65650 CR2032 3-volt battery for 3732 Micrometers
All electronic micrometers include protective case

3732XFL-4

3732XFL-1

S3732CXFLZ

starrett.com 25
