electronIc MIcroMeters

733 electronIc MIcroMeters
(WItH output)

0-24"/0-600MM
®
• With output to cable or DataSure Wireless Systems
733 Electronic Micrometers with Standard Inch Graduations 733 Electronic Micrometers with Standard Millimeter Graduations
Range mm Resolution mm Cat. No. EDP Range in Resolution in
mm
in
EDP
Cat. No.
mm
in
MicroMeters 733XFL-1 W/SLC 66905 0 - 1 76 - 101 0.0001 0.001 733MEXFLZ-50 65441 25 - 50 .984 - 1.968 0.001 0.0001
0 - .984
0 - 25
65440
64239
733MEXFL-25
733XFL-1
0.0001
0.001
0 - 25.4
1 - 2
733MEXFLZ-75
64241
25.4 - 50.8
66079
733XFLZ-2
1.968 - 2.950
50 - 75
2 - 3
2.950 - 3.930
0.001
0.0001
50.8 - 76
733XFLZ-3
64242
733MEXFLZ-100 66080
75 - 100
3 - 4
100 - 125 3.930 - 4.920
64243
733XFLZ-4
733MEXFLZ-125 66081
0.0001
0.001
733XFLZ-5
733MEXFLZ-175 66083
150 - 175 5.900 - 6.890
64245
733XFLZ-6
127 - 152
5 - 6
733MEXFLZ-200 66084
175 - 200 6.890 - 7.870
64246
733XFLZ-7 64244 4 - 5 101 - 127 0.0001 0.001 733MEXFLZ-150 66082 125 - 150 4.920 - 5.900
152 - 178
6 - 7
733XFLZ-8 64247 7 - 8 178 - 203 733MEXFLZ-225 66085 200 - 225 7.870 - 8.850
733XFLZ-9 64248 8 - 9 203 - 228 733MEXFLZ-250 66086 225 - 250 8.850 - 9.840
733XFLZ-10 64249 9 - 10 228 - 254 733MEXFLZ-275 66087 250 - 275 9.840 - 10.820
733XFLZ-11 64250 10 - 11 254 - 279 733MEXFLZ-300 66088 275 - 300 10.820 - 11.810
733XFLZ-12 64251 11 - 12 279 - 305 733MEXFLZ-325 66089 300 - 325 11.810 - 12.790
733XFLZ-13 64415 12 - 13 305 - 330 733MEXFLZ-350 66090 325 - 350 12.790 - 13.770
733XFLZ-14 64416 13 - 14 330 - 355 733MEXFLZ-375 66091 350 - 375 13.770 - 14.760 0.001 0.0001
733XFLZ-15 64417 14 - 15 355 - 381 0.0001 0.001 733MEXFLZ-400 66092 375 - 400 14.760 - 15.740
733XFLZ-16 64418 15 - 16 381 - 406 733MEXFLZ-425 66093 400 - 425 15.740 - 16.730
733XFLZ-17 64419 16 - 17 406 - 432 733MEXFLZ-450 66094 425 - 450 16.730 - 17.710
733XFLZ-18 64420 17 - 18 432 - 457 733MEXFLZ-475 66095 450 - 475 17.710 - 18.700
733XFLZ-19 64421 18 - 19 457 - 482 733MEXFLZ-500 66096 475 - 500 18.700 - 19.680
733XFLZ-20 64422 19 - 20 482 - 508 733MEXFLZ-525 66097 500 - 525 19.680 - 20.660
733XFLZ-21 64423 20 - 21 508 - 533 733MEXFLZ-550 66098 525 - 550 20.660 - 21.650
733XFLZ-22 64424 21 - 22 533 - 559 733MEXFLZ-575 66099 550 - 575 21.650 - 22.630
733XFLZ-23 64425 22 - 23 559 - 584 733MEXFLZ-600 66100 575 - 600 22.630 - 23.620
733XFLZ-24 64426 23 - 24 584 - 609 All except 1" and 0-25mm sizes furnished with standards.
All except 1" size furnished with standards.
733 Electronic Micrometer Accessories
Cat. No. EDP Description
957 66565 Protective case for 733 Micrometers
949 63874 Deluxe padded case for 25mm 733 Micrometers
733SCKB 69888 USB cable to PC (In focused window)
733SCU 69898 USB cable to computer running SPC Data Collection Software
733SCM 69893 SmartCable connection to Multiplexer (7612 , 7613 or RMS 2704)
PT61963 66636 Computer Interface Cable Complete to PC (RS232C)
PT61120 65446 One 3-volt battery CR2450 for 733 Micrometers
733 Micrometer Specifications
Description in mm
Resolution through 4" (100mm) .00005 0.001
Resolution over 4" (100mm) .0001 0.001
Accuracy* ±.0001 ±0.002
* Accuracies above 1" (25mm) are as good as setting to a gage because the mechanical and
733 Micrometer with DataSure End Node electronic components are the same on all ranges.
All electronic micrometers include protective case.
