MIcroMeters

205 steel MIll MIcroMeter 247 MIcroMeter bAll AttAcHMents
0-1" INCH/MM
This micrometer is specially designed for gaging hot metal sheet in Outside micrometers and micrometer heads having spindle sizes
steel mills and has many features for safer, faster, and more accurate listed below can be instantly converted for measuring wall thickness
measurements. Micrometer has rugged construction throughout, and of tubing, split and full bearings, sleeves and other parts with rounded
is attached to a convenient wooden handle, correctly shaped for a firm surfaces by means of the 247 Ball Attachment.
grip. Allows measurements to be made while the micrometer can be feAtures
comfortably held at a safe distance from the hot metal.
• Easily applied by snapping on to end of either anvil or spindle,
reAdAbIlIty feAtures thus permitting two attachments to be used together
• Starrett satin chrome finish – no glare – resists rust • Balls are hardened, measure .200" and 5mm in diameter, and MicroMeters
• Advanced sleeve design with staggered lines and distinct figures move freely in the retainer, insuring positive contact with anvil
for precise and easy readability and spindle
• Quick-reading figures – every thousandth numbered on inch tools • The diameters, .200" or 5mm, of each ball used must be
• Convenient decimal equivalents on inch tools subtracted from the micrometer reading
• Extra long bevel on thimble with heavy cut graduations • All metal construction
eAse-of-HAndlInG feAtures
• Both spindle and anvil are beveled to easily slide onto the work 247 Micrometer Ball Attachments, .200" Diameter Balls
• Large, reversible wing lock nut is easy to lock or release, even Cat. No. EDP Description
For 2, 226 (old style), 230 and 577 Micrometers and 263
when wearing heavy gloves 247A 51174 Micrometer Heads, .235" diameter Anvil and Spindle
• Rugged frame construction and heavy duty spindle of .270" diameter 247B 51175 For 224A, 224AA and 436 Micrometers, .270" diameter anvil and spindle
For 232 Micrometers and 463 Micrometer Heads, .200" diameter
AccurAcy And lonG-lIfe feAtures 247C 51176
anvil and spindle
• Rigid one-piece frame of drop forged steel 247D 51177 For 216, 226 (new style), 231, 436.1, 733, 795, 796, 3732, 1212
• Extremely hard and stable one-piece spindle (the heart of our accuracy) and 1230 Micrometers, .250" diameter anvil and spindle
For 224B through J, 238, 239, 436 Micrometers and 663
• Quick and easy adjustment by either the anvil or by a simple 247E 51178 Micrometer Heads, .300" diameter anvil and spindle
sleeve adjustment 247M Micrometer Ball Attachments, 5mm Diameter Balls
Cat. No. EDP Description
For 2M and 230M Micrometers and 263M Micrometer Heads,
247MA 51179
6mm diameter anvil and spindle
247MB 51180 For 436M Micrometers, 6.8mm diameter anvil and spindle
205 Steel Mill Micrometer 247MD 56691 For 216M and 436.1M Micrometers, 6.35mm diameter anvil and spindle
Cat. No. EDP Range Graduation Description For 224MB through J, 238M, 436M Micrometers and 663M
205HL 50730 0-1" .001" Lock nut, with handle 247ME 56692 Micrometer Heads, 7.6mm diameter anvil and spindle

205HL

247AL

247A
