poInt MIcroMeters

210 screW tHreAd coMpArAtor 760 electronIc screW tHreAd
MIcroMeters coMpArAtor MIcroMeter (WItH output)
0-7/8"/0-22MM 0-1"/0-25MM
This micrometer is ideal for quick comparisons of thread accuracy in Same features as our 210 with electronic readout and the following
screw cutting operations, measuring in small grooves or recesses where additional features and benefits:
regular micrometers cannot be used, and for many other applications. reAdAbIlIty feAtures
NOTE: Does not measure pitch diameter. For such measurements, • Large LCD digital readout is easy to read and reduces errors
575 or 585 Thread Micrometers are recommended.
• Resolution: .00005" and 0.001mm
reAdAbIlIty feAtures
• Conventional inch or millimeter graduations standard
• Starrett satin chrome finish – no glare – resists rust • Attractive no-glare black wrinkle finish on the frame MicroMeters
• Advanced sleeve design with staggered lines and distinct figures • Starrett no-glare satin chrome finish on thimble and sleeve
for precise and easy readability AccurAcy And lonG-lIfe feAtures
• Convenient decimal equivalents on inch reading tools • One 3-volt battery furnished for over a year of normal usage
eAse-of-HAndlInG feAtures
• Automatic OFF after 30 minutes of nonuse
• Balanced frame and thimble design ensure easy handling and full-functIon ActIon feAtures
better readability
• Gracefully designed tapered frame for narrow slots and tight places • Instant inch/millimeter conversion
• "ME" millimeter model turns on in millimeter mode after
AccurAcy And lonG-lIfe feAtures
battery installation
• Rigid steel frame • Measurement HOLD button
• Extremely hard and stable one-piece spindle (the heart of our accuracy) • Zero tool at any position and return to true zero reading
• The 210 has 60° conical anvil and spindle faces with 1/64" • PRESET button to install any reading at any position
(0.4mm) flats on the ends of the points
• Quick and easy adjustment • Ability to install minimum and maximum limits
• RS232 data output port
• Works well with Starrett DataSure Wireless Data Collection Systems
®
210 and 210M Screw Thread Comparator Micrometers (0-7/8" Range) 760 and 760M Electronic Screw Thread Comparator Micrometer
Cat. No. EDP Range Graduation Cat. No. EDP Description
210AP 50731 0-7/8" .001" 760FL 64051 0-1"/0-25mm range, standard inch graduations on shell and thimble
210MAP 64334 0-22mm 0.01mm 760MEFL 66135 0-25mm/0-1" range, standard millimeter graduations on shell
Case for 210 and 210M Screw Thread Comparator Micrometers and thimble
Cat. No. EDP Description Case for 760 and 760M Electronic Screw Thread Comparator Micrometers
910 55397 Attractive protective case Cat. No. EDP Description
731ZZ-2 65163 Attractive protective case
Cable Information for 760 and 760M Electronic Screw Thread Comparator Micrometers
Part No. EDP Description
733SCKB 69888 USB cable to PC (In focused window)
733SCU 69898 USB cable to computer running SPC Data Collection Software
733SCM 69893 Connection to Multiplexer (7612, 7613 or RMS 2704)
PT61963 66636 Computer Interface Cable Complete to PC (RS232C)
PT61120 65446 One 3-Volt Battery CR2450

760MEFL

210AP

starrett.com 59
