MIcroMeters

483, 485 v-AnvIl MIcroMeters 225 WIre MIcroMeters
.093-2"/2-25MM | .078-1" 0-.400"/0-10MM
Used to check out-of-roundness from centerless grinding or other This is another regularly offered special function Starrett micrometer
machining operations. Also used for measuring odd fluted taps, milling designed to measure diameter of wire up to .400" (10mm).
cutters, and reamers. reAdAbIlIty feAtures
reAdAbIlIty feAtures • Starrett satin chrome finish – no glare – resists rust
• Direct measuring of three and five-fluted tools • Advanced sleeve design with staggered lines and distinct figures
MicroMeters eAse-of-HAndlInG feAtures eAse-of-HAndlInG feAtures
• Starrett satin chrome finish – no glare – resists rust
for precise and easy readability
• Advanced sleeve design for precise and easy readability
• Quick-reading figures – every thousandth numbered on inch tools
• Quick-reading figures – every thousandth numbered on inch tools
• Smooth friction thimble for uniform pressure
• Balanced frame and thimble design ensure easy handling and readability
placed on a flat surface
• Ring-type knurled lock nut for quick and sure locking • Hex body which stops the micrometer from rolling over when
• Combination ratchet and speeder for uniform pressure and • The throat is flat to support the wire when measuring
quick adjustment • The anvil and spindle extend below the flat surface
AccurAcy And lonG-lIfe feAtures AccurAcy And lonG-lIfe feAtures
• Rigid one-piece frame of drop forged steel • Extremely hard and stable one-piece spindle (the heart of our accuracy)
• Extremely hard and stable one-piece spindle (the heart of our accuracy) • Quick and easy adjustment
• Carbide facing on spindle and anvils for extra long wear
• Quick and easy adjustment

483, 483M and 485 V-Anvil Micrometers 225 Wire Micrometers (0-.400" Range)
Cat. No. EDP Range Graduation No. of Flutes it will Measure Cat. No. EDP Graduation
T483XRL-1 52491 .093-1" .0001" 3 T225F 50814 .0001"
T483XRL-2 52494 1-2" .0001" 3 225M Wire Micrometers (0-10mm Range)
T485XRL 52497 .078-1" .0001" 5 Cat. No. EDP Graduation
483MXRL-25 56046 2-25mm 0.01mm 3 V225MF 64255 0.001mm
485MXRL 56047 5
Cases for 483, 483M and 485 V-Anvil Micrometers
Cat. No. EDP Description
939 55331 Attractive protective case for 1" and 25mm sizes
483ZZ-2 55332 Attractive protective case for 2" size

T225F
