dIAl IndIcAtors

81, 25, 655 And 656
AGd dIAl IndIcAtors
This comparison table is an aid to help you find the
indicator with the specific graduations and ranges you GROUP 1 GROUP 2 GROUP 3 GROUP 4
IndIca tors and GaGes 81, 25, 655 and 656 AGD Dial Indicators (White Dials Furnished Standard) Group 1 Group 2 Group 3 Group 4
are looking for. Refer to the following pages for the
1-11/16"
2-1/4"
2-3/4"
3-5/8"
exact catalog number and EDP number.
43mm
92mm
57mm
70mm
Range
Graduation
25-109
0-3-0
656-109
.00005"
.006"
.015"
0-6
656-209
25-209
.006"
.015"
0-3-0
.0001" One Rev. Total Dial Reading 81 Indictators 25 Indicators 655 Indicators 656 Indicators
25-116
0-4-0 25-118 655-118 656-118
.0001" .008" .020"
0-8 25-218
0-5-0 81-111 25-111 655-111 656-111
.0001" .010" .025"
0-10 81-211 25-211 655-211 656-211
0.1
–0.10 81-111-624*
.0001" .010" .025"
–0.10
0.1 81-111-630*
0-5-0 25-511* 655-511* 656-511*
.0001" .010" .200"
0-10 25-611* 655-611* 656-611*
0-10-0 656-517*
.0001" .020" .400"
0-20 656-617*
0-5-0 81-124 25-124 655-124 656-124
.00025" .010" .025"
0-10 81-224 25-224 655-224 656-224
0-10-0 81-128 25-128 655-128 656-128
.00025" .020" .050"
0-20 81-228 25-228 655-228 656-228
0-15-0 655-129 656-129
.00025" .030" .075"
0-30 655-229 656-229
0-10-0 81-134 25-134 655-134 656-134
.0005" .020" .050"
0-20 81-234 25-234 655-234 656-234
0-15-0 81-136 25-136 655-136 656-136
.0005" .030" .075"
0-30 81-236 25-236 655-236 656-236
0.3
–0.30 81-136-622*
.0005" .030" .075"
–0.30
0.3 81-136-623*
0-20-0 81-138 25-138 655-138 656-138
.0005" .040" .100"
0-40 81-238 25-238 655-238 656-238
0-25-0 81-131 25-131 655-131 656-131
.0005" .050" .125"
0-50 81-231 25-231 655-231 656-231
.0005" .050" .500" 0-50 25-431* †
.0005" .050" 1.000" 0-50 25-631* †
* With revolution counter on dial
† With top lift mechanism
AGD Design Specifications: Bezel Diameters
Minimum Diameter Maximum Diameter
Design Size Group in mm in mm
0 1" 25mm 1-3/8" 35mm
1 1-3/8" 35mm 2" 50mm
2 2" 50mm 2-3/8" 60mm
AGD
3 2-3/8" 60mm 3" 75mm
4 3" 76mm 3-3/4" 95mm
148
