sHeet MetAl MIcroMeters

764 electronIc sHeet MetAl MIcroMeters reAdAbIlIty feAtures
(WItH output) • Large, right-sized, high-contrast LCD digital

0-1"/0-25MM readout is easy to read and reduces errors
• Resolution: .00005" and 0.001mm
This micrometer is the same as our 222 Micrometer, except that it has an electronic
readout and is available in the 1" (25mm) and 25mm ranges. Rounded anvil gives a • Conventional inch or millimeter graduations standard
point contact for more accurate gaging; flat anvil also available. • Attractive no-glare black wrinkle finish on the frame
• Starrett no-glare satin chrome finish on thimble
764 Electronic Sheet Metal Micrometers, 6" Throat Depth with Standard Inch Graduations on
and sleeve
MicroMeters Cat. No. EDP Description AccurAcy And lonG-lIfe feAtures
Shell and Thimble
• One 3-volt battery furnished for over a year of
66445 0-1"/0-25mm Range, Round Anvil
764AXFL
66525 0-1"/0-25mm Range, Flat Anvil
764BXFL
normal usage
764M Electronic Sheet Metal Micrometers, 150mm Throat Depth with Standard Millimeter
• Automatic OFF after 30 minutes of nonuse
Graduations on Shell and Thimble
Description
EDP
Cat. No.
764MEAXFL 66446 0-25mm/0-1" Range, Round Anvil full-functIon ActIon feAtures
• Instant inch/millimeter conversion
Cable Information for 764 and 764M Electronic Sheet Metal Micrometers
Part No. EDP Description • "ME" millimeter model will turn on in the millimeter
PT61963 66636 Computer Interface Cable Complete to PC (RS232C) mode after installation of a new battery
733SCKB 69888 USB cable to PC (In focused window) • Measurement HOLD button
733SCU 69898 USB cable to computer running SPC Data Collection Software
733SCM 69893 Connection to Multiplexer (7612, 7613 or RMS 2704) • Ability to zero tool at any position
PT61120 65446 One 3-Volt Battery CR2450 • Ability to retain and return to the true zero reading
Packed one in a box without case.
of the micrometer
• PRESET button to install any reading at any position
• Ability to install minimum and maximum limits
• RS232 data output port
• Works well with Starrett DataSure Wireless Data
®
764AXFL Collection Systems
