electronIc bore GAGes

®
781bxt Accubore electronIc bore GAGes
See specifications on previous pages

781BXT AccuBore Electronic Bore Gage Set – 2-Point Contact (.080-.250" [2-6 mm] Range)
Range
Cat. No. EDP in mm Number of Heads Number of Rings
S781BXTBZ 72998 .080-.250 2-6 5 3
781BXT AccuBore Electronic Bore Gage Sets –3-Point Contact (.250-8" [6-200mm] Range – Fixed Anvils)
Range mm Number of Heads Number of Rings
EDP
Cat. No.
Bore GaGes S781BXTCZ 72997 .250-.375 6-10 2 5 3 3 1 3 2 3
in
72992
.250-.750
S781BXTHZ
6-20
10-20
S781BXTDZ
.375-.750
72996
.750-2.00
S781BXTEZ
72995
20-50
S781BXTJZ
72994
S781BXTFZ
2.00-4.00
50-100
4.00-6.00
S781BXTKZ 72991 .750-4.00 20-100 6 3 2 4 2 1
72990
100-150
S781BXTGZ 72993 4.00-8.00 100-200 4 4
S781BXTLZ 72989 6.00-8.00 150-200 2 1
Larger sizes available on special order.
Gages are also available with dial indicators on special order.
Accessories for 781BXT Electronic Internal Micrometers
Required for Initial Bluetooth Connection
®
Part No. EDP Description 1 Device > 1 Devices
PT61055 72941 770B Output Cable to USB
PT61057 72942 770B Output Cable to USB with Footswitch
Free VMUX Software - 1 channel; visit starrett.com x
Bluetooth 4.0 dongle to PC VMUX Lite (1channel);
®
PT02497 73447 x x
VMUX standard (8 channels)
PT60996 72945 VMUX Standard Software (up to 32 tools) x
PT99492 65650 Two 3-Volt Batteries, CR2032
PT02498 73024 Bluetooth 4.0 Indicator for 0.080-0.75" gages
®
PT02499 73025 Bluetooth 4.0 Indicator for 0.75-12" gages
®
Larger sizes available on special order.
Gages are also available with dial indicators on special order.
Extensions from 2-1/2 - 6" can be added to the 781XT, 781BXTZ-500
enabling internal measurements in deep hole bores

770BXTZ-250 Bore Gage with
S781BXTGZ PT24272 Depth Stop Collar
