HeIGHt GAGe AccessorIes
Right: PT08680A
Middle: PT08962A
deptH GAGe AttAcHMents for HeIGHt GAGes
Left: PT05409A
These attachments replace standard scribers and measure the depths of holes and slots, recesses; inside of
jigs, fixtures; and over high projections.
They have adjustable rods which are held in the desired position by a knurled binding nut. The ends have a
slight radius for point contact on the work.

Depth Gage Attachments for Height Gages
Part No. EDP Rod Length Fits Starrett Height Gage No./Size
PT08962A 51233 6" (150mm) 255 8", 12", 18", 300mm, 450mm
254 12", 18", 24", 300mm, 450mm, 600mm and all Metric and English 259, 180 and
PT05409A 51227 8" (200mm) HeigHt gages
240, 3752 120 (300mm) and 240 (600mm), 755 240 (600mm)
PT08680A 51383 6" (150mm) 751

258rrb, 258rrbM reverse reAdInG 258r, 258Mr rIser blocKs for 258
™
blocKs for 258 dIGI-cHeK HeIGHt GAGe ™
dIGI-cHeK HeIGHt GAGe
™
Used on 258 DIGI-CHEK Height Gages for the precise calibration Increases the range of Inch reading 258 DIGI-CHEK Height Gages by
™
of working gages and for setting dial bore gages. The block fits in 10" and metric reading 258 DIGI-CHEKs by 250mm. Heavily flanged
™
alternate inch positions, its tongue entering the odd numbers and its for rigidity and stability. Both top and base have three ground and
groove entering the even numbers of the gage block stack. lapped pads to match the pads on the DIGI-CHEK base. Retaining
™
plate prevents the DIGI-CHEK from being pushed or sliding off the
™
258RRB and 258RRBM Reverse Reading Blocks pads. Attractive black wrinkle finish. If desired, riser blocks can be
Cat. No. EDP Description stacked one on top of another.
HG 258.RRB 92433 Fits 12", 18" and 24" Gages
HG 258.RRBM 92434 Fits 300mm, 450mm and 600mm Gages
258R Riser Blocks (10" Blocks)
Cat. No. EDP Accuracy For:
HG 258.R 99865 ±. 000040" 12" Gage
HG 258.RA 99866 18" Gage
258MR Riser Blocks (250mm Blocks)
Cat. No. EDP Accuracy For:
HG 258.MR 99867 ±0.001mm 300mm Gage
HG 258.MRA 99868 450mm Gage

258R
258RRB

starrett.com 119
