dIAl HeIGHt GAGes

3250 dIAl HeIGHt GAGes feAtures & specIfIcAtIons
0-6"/0-150MM • Sharp, clear dial graduations of .001" or 2mm in
one revolution
The compact 3250 Dial Height Gage is a very useful tool for machinists and
inspectors. Applications include scribing lines for layout, height measurement • Sharp, black graduations on the satin chrome finish
(with or without dial test indicator), and depth measurement (with optional bar every .100" or 1mm
attachment). It is simple to use, reliable, accurate, and fits into most toolboxes. • Fine adjustment thumb roll for precision measurements
• Vertical bar set back from the edge for better stability
HeigHt gages 3250Z-6 69865 0-6" .001" Dial Height Gage, English • Base clearance allows the gage to measure full gage
3250 Height Gages
• Hardened, ground, and lapped base with finger
Range
Dial Grads
Description
EDP
Cat. No.
grooves for control and ease of movement
3250MZ-150
Dial Height Gage, Metric
69861
0-150mm
0.20mm
Depth Attachment
51383
range of 0 - 6" or 150mm
PT08680A
• Dial lock screw
• Lock to hold the slide in position
• The auxiliary scriber has a rounded nose for cutting
clean, sharp lines with smoothness and less pressure
• Hardened, stainless steel bar, rack, gears, scriber, and
scriber carrier
• Positive spring-loaded double pinion anti-backlash control
• Includes metal case

3250-6 in case

3250-6
