electronIc HeIGHt GAGes

3751 electronIc HeIGHt GAGe (WItHout output) reAdAbIlIty feAtures
0-6"/150MM • Easy-to-read LCD .32" high characters
AccurAcy And lonG lIfe desIGn feAtures
This height gage is light, portable and easy to use for vertical measurements
within its range. • Hardened, stainless steel bar for long life
• Depth attachment PT08680A available for measuring
depth of holes, slots, and recesses
3751 Electronic Height Gage (0-6"/150mm Range)
Cat. No. EDP Description • Fine adjustment thumb roll for precision measurements
3751AZ-6/150 12221 Height Gage, in Case • Rounded nose scriber cuts clean, sharp lines with
Accessories and Cables for 3751 Electronic Height Gage smoothness and less pressure
Part No. EDP Description
PT99492 65650 One 3-Volt Batteries, CR2032 • Lock to hold the slide in position HeigHt gages
PT08680A 51383 Depth Attachment for 6" (150mm) Height Gages • Hardened, ground, and lapped base with finger
947 56756 Wood Case Only
grooves provides ease of movement
• Easy access to single long-life battery, 3-volt CR2032
• Vertical bar is back from the edge of the nose for
better stability
• Scriber can reference zero from the bottom of the base
to get the full 6" (150mm) usable range
• Linear Accuracy: ±.001" (± 0.02mm)
• Resolution: .0005" (0.01mm)
ActIon feAtures WItH tHree control buttons
• Inch-millimeter conversion
• Zero at any position
• Manual ON/OFF plus a built in automatic OFF after 5
minutes of nonuse

3751AZ-6/150
