test IndIcAtors

®
711, 711M lAst Word dIAl test IndIcAtors otHer feAtures Include:
.030", 0.7MM • Ideal for precise measurements in all machining,
layout, and inspection work
The venerable Last Word Dial Test Indicator is among the most versatile available. • Smooth, jeweled lever action
IndIca tors and GaGes bore application, the operator will always know what the correct reading is. • Hard chrome-plated ratchet contact point
Their small size and variety of attachments will handle all jobs with ease and accuracy.
• Positive reversing switch
A very useful feature is the shaded dial – when used with a mirror, such as in a jig
• Swiveling tubular body
Individual Contact Points (Fit All 711 Models)
• Easy reading dials, half yellow for clarity
Ball Diameter
Length
• Variety of attachments available to suit the application.
mm
in
mm
Part No.
in
Material
EDP
70945
PT07137
0.9
.035
• Indicators having "C" in the catalog number are
70944
1.6
Steel
.062
5/32
4
PT07136
furnished with 3 interchangeable steel contact
PT07087
PT07137X
52964
.035
interchangeable steel contact point, PT07087.
1.6
PT07136X
52965
.062
Carbide points available as listed.
.120
3
52966
PT07087X 70912 5/32 4 .120 3 0.9 Carbide points. All other indicators are furnished with one
711 Last Word Dial Test Indicators
®
Dial Steel Contact Points
Cat. No. EDP Grad. Range Reading Length Ball Diameter Description 711LPSZ Indicator with
711FSAZ 52925 Indicator with universal shank complete with long Universal Friction Holder
and Shank
711FSBZ 52927 One: and short arm, body clamp
711FSZ 52929 .001" .030" 0-15-0 5/32" (4mm) Indicator with gooseneck shank
.120" (3mm) Indicator with body clamp only
711GPSZ 52944
Indicator with universal friction holder with shank
Three:
.035" (0.9mm)
711GCSZ 52943 .001" .030" 0-15-0 5/32" (4mm) Indicator complete with all attachments*
.062" (1.6mm)
.120" (3mm)
711HSAZ 52951 Indicator with universal shank complete with long
711HSZ 52953 One: and short arm, body clamp
.0005" .030" 0-15-0 5/32" (4mm)
711LPSZ 52958 .120" (3mm) Indicator with body clamp only
Indicator with universal friction holder with shank
Three:
.035" (0.9mm)
711LCSZ 52957 .0005" .030" 0-15-0 5/32" (4mm) Indicator complete with all attachments*
.062" (1.6mm)
.120" (3mm)
711M Last Word Dial Test Indicators
®
Dial Steel Contact Points
Cat. No. EDP Grad. Range Description
Reading Length Ball Diameter
711MFSAZ 52926 Indicator with universal shank complete with long
711MFSZ 52930 One: and short arm, body clamp
0.01mm 0.7mm 0-35-0 5/32" (4mm)
711MGPSZ 52946 .120" (3mm) Indicator with body clamp only
Indicator with universal friction holder with shank
Three:
.035" (0.9mm)
711MGCSZ 52945 0.01mm 0.7mm 0-35-0 5/32" (4mm) Indicator complete with all attachments*
.062" (1.6mm)
.120" (3mm)
*Attachments include 3 contact points – body clamp – universal friction holder with shank – universal shank complete with long and short arm – double-jointed
attachment – height gage attachment – surface gage attachment – coupling with 3/16" (4.8mm) hole.
711FS-GS
