dIAl IndIcAtors

25 dIAl IndIcAtors 25 Dial Indicators with Jewel Bearings
Range Dial
AGD GROUP 2 Cat. No. EDP Graduation One Rev. Total Reading Stem Dia.
25-151J 67644
RANGES UP TO 1" AND 25MM 25-151J-8 68646 0.001mm 0.1mm 0.25mm 0-50-0 .375" (9.5mm)
25-251J 68118
These indicators have a shockless, hardened steel gear train and jewel 25-251J-8 68647 0.001mm 0.1mm 0.25mm 0-100 .375" (9.5mm)
bearings, except where noted. They are furnished with a lug-on-center 25-161J 53250 0.002mm 0.2mm 0.5mm 0-10-0 .375" (9.5mm)
back. Anti magnetic mechanism is optional for all models. Special non-shock 25-161J-8 64651
25-261J 53281
mechanism is available for all models except 25-109, 25-209 and 25-116. 25-261J-8 64652 0.002mm 0.2mm 0.5mm 0-20 .375" (9.5mm)
For more information on these and other attachments, accessories and 25-171J 68643 0.005mm 0.5mm 1.25mm 0-25-0 .375"
contact points, refer to the end of the AGD Dial Indicator listings. For dial 25-181J 53252 0.01mm 1.0mm 2.5mm 0-50-0 .375" (9.5mm) IndIca tors and GaGes
25-181J-8 64653
styles, see previous pages. 25-281J 53283
25-281J-8 64654 0.01mm 1.0mm 2.5mm 0-100 .375" (9.5mm)
If lift lever is desired, indicator must be ordered with case stem cap. 25-381J 53289
25-381J-8 64655 0.01mm 1.0mm 10mm 0-50-0 .375" (9.5mm)
25-481J 53297 0.01mm 1.0mm 10mm 0-100 .375" (9.5mm)
25-481J-8 64656
25-781J 53305 0.01mm 1.0mm 25mm 0-50-0 .375" (9.5mm)
25-781J-8 64657
25-881J 53307
25-881J-8 64658 0.01mm 1.0mm 25mm 0-100 .375" (9.5mm)

25 Dial Indicators with Jewel Bearings
Range Dial
Cat. No. EDP Graduation One Rev. Total Reading
25-109J 53222 .00005" .006" .015" 0-3-0
25-209J 53254 0-6
25-116J 53225 .0001" .006" .015" 0-3-0
25-118J 53226 .0001" .008" .020" 0-4-0
25-218J 53257 0-8
25-111J 53223 .0001" .010" .025" 0-5-0
25-211J 53255 0-10
25-511J 53299 .0001" .010" .200" 0-5-0
25-111J 25-161J 25-611J 53301 0-10
25-124J 53228 .00025" .010" .025" 0-5-0
25-224J 53259 0-10
25-128J 53230 0-10-0
25-228J 53261 .00025" .020" .050" 0-20
25-134J 53234 0-10-0
11/32" (8.7) 1/4" (6.4) 25-234J 53265 .0005" .020" .050" 0-20
25-136J 53236 .0005" 0.03 .075" 0-15-0
25-236J 53267 0-30
25-138J 53238 .0005" .040" .100" 0-20-0
1 -0+ 1 25-238J 53269 0-40
2 2 2-1/16" (52) 25-131J 53232 .0005" .050" .125" 0-25-0
2-1/4" (57) 25-231J 53263 .125"
3 3 1-3/4" (44) 25-431J 53292 .0005" .050" .500" 0-50
4 5 4 25-631J 53304 1.000"
23/32" (18) 25-142J 53242 .001" .020" .050" 0-10-0
.375" (9.5) 25-242J 53273 0-20
0-15-0
53244
25-143J
25-243J 53275 .001" .030" .075" 0-30
3/4" (19) 25-144J 53246 0-20-0
25-244J 53277 .001" .040" .100" 0-40
25-145J 53248 0-25-0
1/4" (6.3) .001" .050" .125"
25-245J 53279 0-50
25-141J 53240 0-50-0
Free drafting template available for this size. 25-241J 53271 .001" .100" .250" 0-100
Write The L. S. Starrett Co. at: 25-341/5J 53285 .001" .100" .500" 0-50-0
121 Crescent Street 25-441/5J 53293
Athol, MA 01331. .001" .100" .500" 0-100
25-441/5J W/SLC* 66864
25-341J 53287 .001" .100" 1.000" 0-50-0
25-441J 53295
15/32" (12) 25-441/J W/SLC* 66863 .001" .100" 1.000" 0-100
25 Dial Indicators with Jewel Bearings
Range Dial
Cat. No. EDP Graduation One Rev. Total Reading
25-441J with top lift 656-129J case stem cap design 25-341/5P 53286 .001" .100" .500" 0-50-0
required for use with lift lever 25-441/5P 53294 0-100
See page 171 25-341P 53288 .001" .100" 1.000" 0-50-0
25-441P 53296 0-100
* Includes redemption card for Standard Letter of Certification.
