dIAl IndIcAtors

253 dIAl IndIcAtor sets
INCH AND MILLIMETER READING
These sets provide in one handy, compact kit three 25 Dial Indicators to handle most gaging
IndIca tors and GaGes indicators are furnished with jewel bearings.
jobs at a minimum cost. Sets are ideal for tool and die shops, machine shops and toolrooms
having occasional work where a heavy investment in dial indicators would not be practical. The

253 Dial Indicator Sets
EDP
Cat. No.
Description
Set of 3 Inch Reading Dial Indicators: 25-111J, 25-131J and 25-441J
51218
S253Z
Set of 3 Millimeter Reading Dial Indicators: 25-161J, 25-181J and 25-881J
56283
S253MZ
Sets furnished in attractive, protective case.
655 dIAl IndIcAtors
Range
Cat. No.
AGD GROUP 3 655 Dial Indicators Graduation One Rev. Total Dial Reading Stem Dia.
EDP
655-161J 53533
RANGES UP TO 1" AND 25MM 655-161J-8 64659 0.002mm 0.2mm 0.5mm 0-10-0 .375" (9.5mm)
655-261J 53603
These indicators have a shockless, hardened steel gear train and jewel 655-261J-8 64660 0.002mm 0.2mm 0.5mm 0-20 .375" (9.5mm)
bearings. They are furnished with a lug-on-center back. Antimagnetic 655-181J 53535 0.01mm 1.0mm 2.5mm 0-50-0 .375" (9.5mm)
and special non-shock mechanisms are options available for all 655-181J-8 64661
53605
655-281J
models. For more information on these and other attachments, 655-281J-8 64868 0.01mm 1.0mm 2.5mm 0-100 .375" (9.5mm)
accessories and contact points, refer to the end of the AGD Dial 655-881J 56229 0.01mm 1.0mm 25mm 0-100 .375" (9.5mm)
Indicator listings. For dial styles, see previous pages. 655-881J-8 64869
If lift lever is desired, indicator must be ordered with case stem cap. 655 Dial Indicators
Range Dial
Cat. No. EDP Graduation One Rev. Total Reading
655-118J 53507 .0001" .008" .020" 0-4-0
655-111J 53505 .0001" .010" .025" 0-5-0
655-211J 53537 0-10
655-511J 53615 .0001" .010" .200" 0-5-0
655-611J 53617 0-10
655-124J 53509 .00025" .010" .025" 0-5-0
655-224J 53539 0-10
655-128J 53511 .00025" .020" .050" 0-10-0
655-228J 53541 0-20
655-129J 53513 0-15-0
655-229J 53543 .00025" .030" .075" 0-30
655-134J 53517 0-10-0
655-234J 53587 .0005" .020" .050" 0-20
655-111J 655-161J-8 655-136J 53519 0-15-0
655-236J 53589 .0005" .030" .075" 0-30
655-138J 53521 .0005" .040" .100" 0-20-0
655-238J 53591 0-40
655-131J 53515 .0005" .050" .125" 0-25-0
11/32" (8.7) 655-231J 53585 0-50
1/4" (6.3) 655-142J 53525 .001" .020" .050" 0-10-0
655-242J 53595 0-20
1/4" (6.4) 655-143J 53527 0-15-0
0 655-243J 53597 .001" .030" .075" 0-30
5 5
2-1/2" 655-144J 53529 0-20-0
2-3/4" (63.5) 655-244J 53599 .001" .040" .100" 0-40
(69.9) 3/4" 655-145J 53531 .001" .050" .125" 0-25-0
(19) 655-245J 53601 0-50
7/16" 655-141J 53523 .001" .100" .250" 0-50-0
655-241J
53593
0-100
(11) 655-341/5J 53607 0-50-0
3/8" (9.5) .001" .100" .500"
655-441/5J 53611 0-100
5/8" (16) 1-7/8" (47.6) 655-341J 53609 0-50-0
655-441J 53613 .001" .100" 1.000" 0-100
655-131J with top lift 655-341J with stem cap
