Page 272 - catalgo33

coMbInAtIon sets

blAdes for coMbInAtIon squAres, sets And bevel protrActors
INCH, MILLIMETER AND INCH/MILLIMETER
The blades listed below fit any head according to the sizes noted in the charts on all combination squares, combination sets and bevel
protractors. The 12", 18", 24", 36" and 48" and 300mm and 600mm sizes are interchangeable. Exception: Starrett 33J and 8 Combination
Squares. (For these, see 33J and 8 listings.)

Inch Blades Only for Combination Squares, Sets and Bevel Protractors
Cat. No. EDP Size Approx. Width x Thickness Graduation Finish
B4-4R 50076 4" 5/8 x 1/16" 4R – 8ths, 16ths, Quick Reading 32nds, 64ths Regular
SquareS CB4-16R 50078 4" 5/8 x 1/16" 16R – Quick Reading 32nds, 64ths, Aircraft Quick Reading 50ths, 100ths Satin Chrome
Satin Chrome
50077
CB4-4R
Regular
B6-4R
50079
6"
3/4 x 5/64"
4R – 8ths, 16ths, Quick Reading 32nds, 64ths
50080
CB6-4R
Satin Chrome
B6-16R
CB6-16R 50081 6" 3/4 x 5/64" 16R – Quick Reading 32nds, 64ths, Aircraft Quick Reading 50ths, 100ths Regular
50082
Satin Chrome
B12-4R 50083 12" 1 x 3/32" 4R – 8ths, 16ths, Quick Reading 32nds, 64ths Regular
CB12-4R 50084 Satin Chrome
CB12-6R 50085 12" 1 x 3/32" 6R – Aircraft Quick Reading 50ths and 10ths Satin Chrome
B12-16R 50086 12" 1 x 3/32" 16R – Quick Reading 32nds, 64ths, Aircraft Quick Reading 50ths, 100ths Regular
CB12-16R 50087 Satin Chrome
B18-4R 50088 18" 1 x 3/32" 4R – 8ths, 16ths, Quick Reading 32nds, 64ths Regular
CB18-4R 50089 Satin Chrome
B18-16R 50090 18" 1 x 3/32" 16R – Quick Reading 32nds, 64ths, Aircraft Quick Reading 50ths, 100ths Regular
CB18-16R 50091 Satin Chrome
B24-4R 50092 24" 1 x 3/32" 4R – 8ths, 16ths, Quick Reading 32nds, 64ths Regular
CB24-4R 50093 Satin Chrome
CB24-6R 50094 24" 1 x 3/32" 6R – Aircraft Quick Reading 50ths and 10ths Satin Chrome
B24-16R 50095 24" 1 x 3/32" 16R – Quick Reading 32nds, 64ths, Aircraft Quick Reading 50ths, 100ths Regular
CB24-16R 50096 Satin Chrome
CB36-4R 50097 36" 1 x 3/32" 4R – 8ths, 16ths, Quick Reading 32nds, 64ths Satin Chrome
CB36-16R 50098 16R – Quick Reading 32nds, 64ths, Aircraft Quick Reading 50ths, 100ths Satin Chrome
CB48-4R 67102 48" 1 x 3/32" 4R – 8ths, 16ths, Quick Reading 32nds, 64ths Satin Chrome
Millimeter Blades Only for Combination Squares, Sets and Bevel Protractors
Cat. No. EDP Size Approx. Width x Thickness Graduation Finish
B150-35 55985 150mm 19 x 2mm 35 – mm and 1/2mm Both Sides Regular
CB150-35 55988 Satin Chrome
B300-35 55986 300mm 25 x 2.4mm 35 – mm and 1/2mm Both Sides Regular
CB300-35 55989 Satin Chrome
B600-35 55987 600mm 25 x 2.4mm 35 – mm and 1/2mm Both Sides Regular
CB600-35 55990 Satin Chrome
Inch and Millimeter Blades Only for Combination Squares, Sets and Bevel Protractors
Cat. No. EDP Size Approx. Width x Thickness Graduation Finish
B150-36 55991 150mm and 5-3/4" 19 x 2mm 36 – 1/2mm and 32nds One Side; mm and 64ths Reverse Side Regular
CB150-36 55992 Satin Chrome
B300-36 50101 300mm and 11-3/4" 25 x 2.4mm 36 – 1/2mm and 32nds One Side; mm and 64ths Reverse Side Regular
CB300-36 55993 Satin Chrome
B600-36 50102 600mm and 23-1/2" 25 x 2.4mm 36 – 1/2mm and 32nds One Side; mm and 64ths Reverse Side Regular
CB600-36 55994 Satin Chrome
All sizes packed one per envelope.
CB12-4R
