coMbInAtIon squAre blAdes

squAre HeAds, center HeAds And protrActor HeAds for
coMbInAtIon squAres, coMbInAtIon sets And bevel protrActors
The heads listed fit any blade according to the sizes noted in the charts on all combination squares,
combination sets and bevel protractors. Sizes 12", 18", 24", 36", and 48" and 300mm and 600mm are
interchangeable. When ordering, specify complete catalog number and length of blade. Exception: Starrett
33J and 8 Combination Squares. (For these, see 33J and 8 listings.) H11-1224

Square Heads Only for Combination Squares, Combination Sets and Bevel Protractors
Forged and Hardened Steel with Smooth
Cast Iron Black Wrinkle Finish Black Enamel Finish
Cat. No. EDP Cat. No. EDP Fits Blade Size
H11-4 50069 H33-4 50223 4"
H11-6 50070 H33-6 50224 6" SquareS
12" (300mm)
H11-1224 50071 H33-1224 50225 18"
24" (600mm)
Center Heads Only for Combination Squares, Combination Sets and Bevel Protractors
Forged and Hardened Steel with Smooth
Cast Iron Black Wrinkle Finish Black Enamel Finish
Cat. No. EDP Cat. No. EDP Fits Blade Size
C11-4 50072 C33-4 50226 4"
C11-6 50073 C33-6 50227 6"
12" (300mm)
C11-1224 50074 C33-1224 50228 18"
24" (600mm)
Protractor Heads – Cast Iron (Fits blades 12" and up) for Combination Squares, Combination Sets and Bevel Protractors
Reversible Nonreversible
Cat. No. EDP Cat. No. EDP Finish C33-1224
PR-1224W 52525 PNR-1224W 50107 Black Wrinkle
CPR-1224W 64601 CPNR-1224W 50108 Black Wrinkle, Chrome on Turret
PR-1224S 52515 Black Smooth
CPR-1224S 52516 Black Smooth, Chrome on Turret
For prices of lock bolts, contact the Parts Department.
4" Center Head Max. Inspection Dia.: 3.125"
6" Center Head Max. Inspection Dia.: 4.3"
12"-24" Center Head Max. Inspection Dia.: 5.3"
PR-1224S
