AnvIl MIcroMeters

714 electronIc IntercHAnGeAble AnvIl outsIde reAdAbIlIty feAtures
MIcroMeters (WItH output) • Large, right-sized, high-contrast LCD digital

0-24"/0-600MM readout is easy to read and reduces errors
• Resolution – .00005" and 0.001mm
This micrometer is the same as our 224 Micrometers except that it has an electronic
readout and the following extra features and benefits: • Conventional inch or millimeter graduations standard
• Starrett no-glare satin chrome finish on thimble
and sleeve
714 Electronic Interchangeable Anvil Micrometers With Standard Inch Graduations on Shell and Thimble AccurAcy And lonG-lIfe feAtures
MicroMeters 714AAFLZ 64427 in Approx. mm in mm full-functIon ActIon feAtures
Range
Resolution
EDP
Cat. No.
• One 3-volt battery furnished for dependable power
0-4
.00005
0-101
0.001
and over one year's normal usage
51-152
714AFLZ
2-6
64428
• Automatic OFF after 30 minutes of nonuse
6-9
714BFLZ
152-228
64429
6-12
64430
152-305
714GFLZ
714CFLZ
64432
12-16
714DFLZ 64431 9-12 228-305 .0001 0.001 • Instant inch/millimeter conversion
305-406
714EFLZ 64433 16-20 406-508 • "ME" millimeter models will turn on in the
714JFLZ 64434 20-24 508-609 millimeter mode after installation of a new battery
714M Electronic Interchangeable Anvil Micrometers With Standard Millimeter Graduations on • Measurement HOLD button
Shell and Thimble
Range Resolution • Ability to zero tool at any position
EDP
Cat. No. mm Approx. in mm in • Ability to retain and return to the true zero reading
714MEAAFLZ 66108 0-100 0-3.930 0.001 .00005
714MEAFLZ 66109 50-150 1.968-5.900 of the micrometer
714MEGFLZ 66111 150-300 5.900-11.810 • PRESET button to install any reading at any position
714MEDFLZ 66112 300-400 11.810-15.740 0.001 .0001 • Ability to install minimum and maximum limits
714MEEFLZ 66113 400-500 15.740-19.680
714MEJFLZ 66110 500-600 19.680-23.620 • Output data to Starrett SPC Plus hardware and
Cable Information for 714 and 714M Electronic Interchangeable Anvil Micrometers software and to PCs
Part No. EDP Description • Works well with Starrett DataSure Wireless Data
®
PT61963 66636 Computer Interface Cable Complete to PC (RS232C)
733SCKB 69888 USB cable to PC (In focused window) Collection Systems
733SCU 69898 USB cable to computer running SPC Data Collection Software
733SCM 69893 Connection to Multiplexer (7612, 7613 or RMS 2704)
PT61120 65446 One 3-Volt Battery CR2450
Adjusting wrenches furnished with each tool.
Micrometer furnished in protective case with 234 Standards.
714MEAAFLZ

714EFLZ
