MIcroMeter HeAds

263 And 1263 MIcroMeter HeAds 4-1/2" (105)
0-1"/0-25MM
• Reading surfaces satin-finished for easy readability 1-9/32" (32.51) 45/64" (17.89)
• No-glare, satin chrome finish on the 263, rust-resistant,
stainless steel on the 1263
• Available with reverse reading, if needed
• Ring-type knurled lock nut for quick and sure locking
MicroMeters combination ratchet and speeder for uniform pressure .235" (5.969) 39/64" (15.47)
• Choice of smooth friction thimble for uniform pressure,

and quicker adjustment, or a plain micrometer head that
depends on your own "feel"
• Spindle face available plain or with carbide
.3750" (9.5250)
39/64" (15.47)
.3745" (9.5123)
• Furnished with 1/2" (12.7mm) or 3/8" (9.5mm) diameter 39/64" (15.61) ( ) 39/64" (15.47)
clamping surface 263L-38TN (0-1") dimensions
263 and 263M Micrometer Heads
Cat. No. EDP Range Graduation
263P 51251 4-1/8" (105)
263P-38 67108
263P-38TN 67110 2-3/32" (53)
263L 51253
263XL 51265 0-1" .001" 1-1/4" (53) 3/4" (19)
263L-38 67109
263L-38TN 67111
263RL 51254
263FL 51256
RV263RL 57071
T263P 51258
T263L 51260 0-1" .0001"
T263XL 65054
T263RL 51261 .235" (5.969)
263MP* 51275
263ML* 51276 0-25mm 0.01mm 5/8" (16) 5/8" (16)
263MRL* 51257 .4999" ( )
12.000 or (+.000)
263MXL* 65055 .4994" 12.700 (-.007)
V263MRL* 55962
RV263MRL* 64948 0-25mm 0.001mm 263P (0-1") and 263MP (0-25mm) dimensions
V263MXRL* 65056
1263 and 1263M Stainless Steel Micrometer Heads
Cat. No. EDP Range Graduation
1263L 53200 0-1" .001"
1263RL 53201 4-61/64" (126)
T1263RL 53203 0-1" .0001" 2-5/16" (59)
V1263MRL* 64345 0-25mm 0.001mm
*0-25mm models specify clamping diameter 12 or 12.7mm. 12.7mm sent unless 1-1/4" (32) 3/4" (19)
otherwise ordered.

263RL
.235" (6.0)
( )
.4999" 12.000 (+.000) 5/8" (16) 25/64" (10)
.4994" 12.700 (-.007) 5/8" (16)

263RL (0-1") and 263MRL (0-25mm) dimensions
