specIAl functIon IndIcAtors

668 sHAft AlIGnMent clAMp sets feAtures
The 668 Shaft Alignment Clamp is designed for fast, precise alignment of motors, pumps, • Lightweight clamp design made of black
compressors, etc. This system is capable of addressing radial and angular misalignment anodized aluminum
problems and can be set up within minutes. • Rigid 3/8" diameter stainless steel indicator posts
IndIca tors and GaGes Cat. No. EDP Description • Heavy-duty roller chain can accommodate up
provided in three lengths (5", 7-7/16", and 9")
• Extension plate allows for added radial clearance
668 Shaft Alignment Clamp Sets
67150 1 each: Chain Clamp, Extension Plate, Posts (5", 7-7/16", 9"), without Case
S668A
to a 7-1/2" diameter shaft
S668BZ
67151 2 each: Chain Clamp, Extension Plate, Posts (5", 7-7/16", 9"), with Fitted Case
2 each: Chain Clamp, 196B5 Indicator, PT18724 Snug, Extension Plate, Posts (5",
• Sets are available with either two 196B5 or
S668CZ 67152
7-7/16", 9"), with Fitted Case
81-141J Indicators
2 each: Chain Clamp, 81-141J Indicator, 657Y Indicator Attachment, PT18724 Snug,
S668DZ 67153
• Excess roller chain can be secured to the side
Extension Plate, Posts (5", 7-7/16", 9"), with Fitted Case
of the chain clamp
27984-0 -
668 Shaft Alignment Clamp
mounted across from the first clamp to act as
EDP
Photo Key Extra Length Chain: 24" #35 ANSI Chain with Link Individual Components • A second shaft alignment clamp can be
Cat. No.
A 668 67155 Chain Clamp Only a vertical "target" for face alignment
B PT99529 67454 Extension Plate Screw, Washer
C PT27981 67302 5" Post
D 657G 52753 7-7/16" Post
E PT27982 67303 9" Post
F PT18724 50710 Snug Complete
G 657Y 52765 Indicator Attachment

A

B

F

G

C

D

E

194
